FlashLink® Certified Vaccine ULT PDF Data Logger
Model: 40570
FEATURES
- Monitor vaccines in ultra-low temperatures
- Ideal for storage and transport with dry ice
- Compatible with CDC guidelines
- 21 CFR Part 11 compliant software
- Single channel, external sensor
- Automatically generates PDF, CSV and Daily Log reports
- Audible and/or visual alarms
- Low battery indicator on LCD
- Quick disconnect cable to download logger
- Scroll through recorded data on LCD
APPLICATIONS
Hospitals, Labs, Pharmacies, Storage Refrigerators and Freezers
| Feature | Specification |
|---|---|
| Sensor Measurement Range | -115.6°F to 113°F (-82°C to 45°C) |
| Logger Operating Range | -4.0°F to 122°F (-20°C to 50°C) |
| Temperature Resolution | 0.1°F/°C |
| Accuracy within Normal Operating Range | ±1.0°F from -115.6°F to 113°F (±0.5°C from -82°C to 45°C) |
| Data Capacity | 32,496 data points |
| Data Download Time | 5 seconds typical for 3823 points |
| Multiple Alarm Levels | High & low levels and extreme high and low levels displayed on LCD, with audible buzzer |
| Battery | Two AAA lithium batteries, LCD % remaining power indicator |
| Dimensions/Body | 1.575in x 3.66in x 0.94in (40mm x 93mm x 24mm) |
| Casing | ABS plastic |
| External Sensor | 0.14in Dia x 1.22in L (3.5mm Dia x 31mm L) 3.28ft (1m) Teflon cable with stereo jack connector |
| Weight | 2.24 oz (63.5 grams) |
| Calibration | 2-yr ISO 17025 Calibration Certificate (A2LA), 1-yr NIST Calibration Certificate, and Manufacturer’s Certificate of Compliance available |
| Certification | CE mark, NIST traceable, RoHS, WEEE |
| Display | LCD, Red LED Alarm |
| Waterproof Rating | IP64 (with silicone cap) |
| Storage conditions | -4°F to 122°F (-20°C to 50°C) 0% to 95% RH w/o condensation |
| Shelf Life | 2 years (battery life) |
| System Requirements | Windows PC with current operating system, Adobe Reader |
| Programming | Supplied preconfigured for plug and play. User programmable with FlashLink Program Manager software (Included) |
| Download Requirements | Direct USB connection to PC (No special software required to download logger.) |
| Model | |
|---|---|
| 40570 | Includes Manufacturer’s Certificate of Compliance |
| 40570-01 | Includes 2-yr ISO 17025 Calibration Certificate |
Download FlashLink Certified Vaccine ULT PDF Data Logger Spec Sheet
Flyer: Reusable Temperature Monitors for COVID-19 Vaccine Storage and Handling
Flyer: Reusable Temperature Monitors for COVID-19 Vaccine Storage and Handling (Spanish)
Model 40575 – FlashLink ULT External Aluminum Sensor
- Sensor measures down to -82°C
- 9.8ft (3m) cable length
Model 40576 – FlashLink ULT External Blunt Probe
- Probe measures down to -82°C
- 3.3ft (1m) cable length
FlashLink Program Manager Software 7.1.9
FlashLink Program Manager is a user-friendly and feature-packed software for programming and downloading the FlashLink Mini Multi-Use and USB Reusable Data Loggers. It is available to be downloaded from the link below. A license number is necessary in order to complete the installation.
To download FlashLink Program Manager click on the link below to launch the download form. Refer to the help file in the software for data logger configuration programming.
